Description
12 TO 128 CHANNELS
Boasting safety features, flexible controls and a quality finish, our digital controller range suits the most demanding installations.
Various formats of wired and/or wireless remote can be used to match your working habits.
MAIN FEATURES :
1. Smart Hoist Selection
Each channel has an ADJUST position to quickly operate one hoist without having to deselect and re-select all the others.
Each selector has RGB LED that indicates the status of the channel : On, Off, Adjust, Going Up & Going Down.
2. Phase Reversal Switch
Something has not been wired correctly and one of your hoist is going in the opposite direction ?
By using these switches, you can easily reverse the phase of each channel without modifying your current selection.
3. Local or Remote Control
A switch allows you to select between the 2 control modes and the remote comes with a 15 meters cable as standard, offering the same hoist selection capabilities.
Don’t like to be tied ?
An optional wireless module is available !
OTHERS FEATURES :
· Individual or group control of 12 DC hoists with a capacity ranging from 250 to 1000 kg.
· Controllers can be linked with our digital link system for up to 128 simultaneous channels.
· Thermal-magnectic circuit breakers to protect hoists from surges and short-circuit.
· Group stop if a breaker of the controller or linked system trips, with key for funtion bypass.
· Reset button proceeds to internal checks and makes sure the operator has been made aware an emergency stop happened before the system can be operated again.
· 32A power input, with power out to daisy chain several controllers for power supply.
· Automatic phase alignment of the power input.
· CEE, Harting and Socapex outputs to suit every configuration.
· 13U flight case on wheels with a drawer to store the remote and cable.
· AUX 230V power output for any device such as laptop, phone...
