I-MOTION-SYSTEM

VMK-S SERIES

The VMK-S hoists according to DGUV V17/ BGV C1, DIN 56950:2012-05 and EN 61508 SIL 3 are notable for their innovative feature set and extraordinary flexible handling, whilst satisfying at all times the highest standards of safety.

Available in a range from 125kg to 2500kg, speed 40m/min – 10m/min.

To mention are the two independent, low-noise and maintenance-free brakes with brake gap monitoring, two independent encoders, integrated 4-pole-limit-switch a real-time load-measuring module integrated in the eyelet that gathers the real load data and therefor the overload and underload values, and a temperature sensor that monitors permanently the operating temperature of the motor.

No need to mention that it can be controlled with our I-Motion system of course and operates in the true-zero-speed closed-loop functionality as well.

I-MOTION-SYSTEM

V-MOTION

Our V-Motion Series is the heart of our modular build principle. Its purpose is to control any variable speed device you can imagine and link them into MOVECAT’s I-Motion network. It contains main- and safety processors, the frequency converter (from 1.5KW up to 12.5KW) and basically all the electronics you need to either control MOVECAT’s machinery or even any other machinery (for example hoists, trolleys or podiums) via our I-Motion network on one of our show-consoles.

With our V-Motion-technique, we can even integrate 3rd-party products in our system. A V-Motion provides an LED Display, showing you actual states of the drive right in place, like position load, general “health” and so on. Furthermore, you can use it as a single-drive backup controller for emergency situations or maintenance with up to 70m hybrid connection cable.

I-MOTION-SYSTEM

VMW-S ENTERTAINMENT WINCH

Our VMW-S high speed winch is dedicated to the entertainment market. Plug and Play setup with our I-Motion System, connectable to 52cm trussing, and officially approved for flying artists.

It is manufactured according to BGV C1/DGUV-17, DIN56950, EN61508 (SIL3) and DGUV315-390 checked. Whilst in can lift 125kg it is blazingly fast: 3m per second. Or incredibly slow with our closed-loop system -> 0m per second and 1 second acceleration to full speed and full load.

I-MOTION-SYSTEMEXPERT-T III

The Expert-T III can handle up to 240 Drives at once, provides live back-up (if you use two of them or the I-MOTION-Server), gives you real-time 3D overview of your scenery, is equipped with collisioncontrol, fully synchronized movements and many more features.

SSD Harddrive, 24″ Touchscreen, 3D Interface, and of course UPS are almost as cool as the new extended Hot-Key area for quick access to almost endless functions. Continous development and feedback from our customers worldwide made it the perfect product. Of course, it is approved to BGV-C1 (DGUV 17) and EN61508 (SIL 3). Interfaces to triggers like Artnet, PSN are standard.
