Loadcell

l Safety certification: TUV Rheinland certified SIL3 safety level

l Control object: Chain hoist, lifting platform, track car, screen, etc.

l Motor: Servo motor, 3-phase asynchronous motor

l Redundancy: Ring network, multi-console

l External trigger: DMX, LTC time code

l Direct nodes: 1 control system to 128, and 1 console to 1024

l Safety protection: Over range, limit, under&overload, speed&position deviation

l Control mode: Speed closed loop, position closed loop

l Encoder: 2 encoders: incremental & absolute

l Commissioning Free：Plug and play, no need for softwarepersonnel to be on-site for debugging

l Multi Safety Protections：

Position monitoring: Supportconnection to incremental or absolute encoders for position detection andsoftware protection

Limit monitoring: Support limit switch input and display

Phase sequence error detection

Overload and underload protection: Connect to load cells to achieve overload and underload protection

Loss orreduction of the supply voltage detection

Motor current monitoring

Group halting: During simultaneous operation, an alarm from a single device can trigger a quick shutdown of other devices

l Easy to operate：8x3-positiontravel direction switch for easy local control. Multipleunits to be controlled by a single go button

EXTRA-F Series Products are horizontal moving devices specially designed for the EXTRA-T electric chain hoist. Equipped with the IAC frequency control system, it ensures smooth start and stop during horizontal movement and provides anti-sway functionality when handling loads. It is the perfect solution for opening and closing screens and other horizontal movement needs.

Meet the requirements of EU IGVW SQP2:2018 entertainment professional standards, and ceritified by TUV Rhineland professional institution.

The first TUV BGV-D8/D8+/C1 certified chain hoist in China.


l Safety certification: TUV Rheinland certified, in line with SPQ2 BGV D8/D8+/C1 standard

l Max. speed: 28m/min

l Working load: 0.25T, 0.5T, 08T, 1T, 2T

l Load cell: Optional shackle type or internal integrated

l Safety protection: 4-point limit switch

l Safety feedback: Motor thermal protection switch, brake feedback switch

l Brake: 2*DC

l Chain: In accordance with EN818-7-DAT standard

l Encoder: Three positions for installing encoders

l Work level: ISO:M5

l Protection level: IP66 protection grade, suitable for outdoor

l Safety certification: TUV Rheinland certified SIL3 safety level

l Control object: Chain hoist, lifting platform, track car, screen, etc.

l Motor: Servo motor, 3-phase asynchronous motor

l Redundancy: Ring network, multi-console

l External trigger: DMX, LTC time code

l Direct nodes: 1 control system to 128, and 1 console to 1024

l Safety protection: Over range, limit, under&overload, speed&position deviation

l Control mode: Speed closed loop, position closed loop

l Encoder: 2 encoders: incremental & absolute

l Commissioning Free：Plug and play, no need for softwarepersonnel to be on-site for debugging

l Multi Safety Protections：

Position monitoring: Supportconnection to incremental or absolute encoders for position detection andsoftware protection

Limit monitoring: Support limit switch input and display

Phase sequence error detection

Overload and underload protection: Connect to load cells to achieve overload and underload protection

Loss orreduction of the supply voltage detection

Motor current monitoring

Group halting: During simultaneous operation, an alarm from a single device can trigger a quick shutdown of other devices

l Easy to operate：8x3-positiontravel direction switch for easy local control. Multipleunits to be controlled by a single go button

EXTRA-F Series Products are horizontal moving devices specially designed for the EXTRA-T electric chain hoist. Equipped with the IAC frequency control system, it ensures smooth start and stop during horizontal movement and provides anti-sway functionality when handling loads. It is the perfect solution for opening and closing screens and other horizontal movement needs.
