CAB-30 Cable management system for big loads and heights

• Maximum height – 20m

• 2 or 3m elements (alluminium)

• Crossection 280x51mm

• Self weight 3.3 kg/m

• Cables weight 25kg/m

• Total cable weight up to 450 kg

• Black powder coating finish

• Fixing on truss 30-52cm

• Cable fixing on straight sections by plastic ties

• IGUS plastic bearings in hinges

• CE certified

​

Options

• Custom fixing solutions

• Custom upper fixing elements

• Custom lenght of straight elements

• Increased height

• Custom colour

D 100mm, SWL 125kg, 1-6 ways

• Maximum curtain weight 200 kg
• Maximum aperture up to 20m
• Speed up to 0.5 m/s
• Operated by:
• electrical winch
• hand winch
• pull rope
• walk along

• Power 400V, 3Ph, 50 Hz, 0.55kW
• Steel wire D3mm - winch operated
• Rope D5-8mm - pull rope operated
• Limit switch for open/close position adjusting
• Wall or pipe fixing
• CE sertified

TR6 Curtain track motorised

• CODE: TR6 - L

  L - lenght of the track

• Multiconsoles, multiuser topology
• Service access through Internet
• Individual control of AXES
• Defining GROUPs of AXES
• Grouping movement patterns in CUEs
• Grouping CUEs in SEQUENCES
• Saving/uploading SHOWS to a server or media
• Safe synchronisation, speed, acceleration, position, load control
• Extra e-stops, access control, gate sensors, virtual map
• Safety over industrial network
• Monitoring of drives, brakes, sensors
• Monitoring of safety system status
• Industrial touch screen 18.5”- 21,5”
• 2x Joystics with „dead man” lock
• System lock by key, illuminated e-stop
• Worklights
• Drawer for keyboard and mouse
• Stand on wheels, adjustable height, tilt

AXES CONTROL:

• BECKHOFF automation components
• BECKHOFF industrial PCs
• EMOTRON frequency drives
• EMOTRON AFR regenerative drive
• TRElectronic SIL3 absolute encoders
