Trade fair innovationClaypaky Rhapsodya
Rhapsodya emerges as a groundbreaking, low-noise multi-spectral RGBAL LED fixture meticulously designed for various applications such as touring, live events, theatre, and TV production, and managed by a specially crafted, internally developed firmware algorithm.
It is an evolution of Sinfonya, particularly regarding the focus on quality of optics and color management, and the whisper-quiet operation even at full output. Rhapsodya has a stunning new product design that is sleek and modern, with a double power output compared to Sinfonya.
Besides the innovative features in common with Sinfonya, such as ACCUFRAMETM, a framing system employing dual focal planes, achieving an astounding 40-fold increase in precision when compared to conventional framing systems and TONEDOWNTM, which ensures whisper-quiet operation at just 27dB, Absolute Position control for advanced PAN & TILT capabilities, and LINEGUARD, a new frost system employing two pairs of blades, Rhapsodya gives a technological boost thanks to the new features: AccuTune a precise control over the multicolor LED engine thanks to a new algorithm for vibrant and rich colors optimized for both stage and TV.
COLORSTRING, is an individual LED control for a high level of graphics and color effects, empowering you to create intricate and dynamic lighting displays.
Furthermore, the fixture boasts a cutting-edge Proprietary Optical System, offering an impressive 6° to 60° Zoom range.
Rhapsodya is more than just a fixture; it’s your backstage partner, your on-air star, and your roadie’s dream. Explore its exceptional features and witness the future of lighting innovation.
- Light Source: 1200W RGBAL LED Engine • CRI: up to 95
- 24,000 lm output (in integrating sphere) • R-G-B-A-L color control
- 6°- 60° motorized linear zoom
- 2500K to 10000K virtual CTO
- Proprietary, high-efficiency, new optical system
- 170-millimeter diameter front lens, with high quality tempered glass lenses
- Framing System on 2 focal planes: 4 blades with +/- 60° rotation of the full system
- “Total Curtain” effect allowing the full blackout with each single blade
- Triangular shapes
- COLORMATCH calibration syncing for matching the color temperature to other fixtures • COLORSTRING: individual LED stripe control
- ACCUFRAMETM: 40 times more precise than traditional framing systems
- LINEGUARD: a new frost system using two pairs of blades instead of two individual ones • Heavy frost 5° for wash effect
- Light frost 1° for soft diffusion (interchangeable)
- ABSOLUTE POSITION for advanced Pan & Tilt Control
- TONEDOWNTM for a low noise operation (27dB at full output)
- Fanless modality
- ACCUTUNE: precise control over the multicolor LED engine
- 16-blade Motorized iris
- 24-bit digital dimmer with 4 user-selectable dimming curves
- Digital color filters
- 2 wheels with 6 HD interchangeable rotating gobos each
- Animation wheel with X/Y insertion and rotation
- 4-facets prism with rotation in both direction at variable speed
- Color wheel expansion (with additional deep red, deep green and deep blue options)
- Digital stop-strobe effect
- Advanced firmware for a max. performance and light output control
- 3 personalities for DMX channels
- Control Protocol: DMX, Art-Net, RDM, sACN
- Optional Wireless DMX system (Lumen Radio)
- CloudIO Ready: fully compatible with CloudIO
- Operating Voltage: 100-240V, 50/60 Hz
- Max Power consumption: 1600 VA
- Selectable fan options, DMX controlled
- New housing and external design
- 48.1 Kg (106.04 lbs)
- 407x452x108mm (base dimension) – 877mm with vertical head (h)
- Distance between two fixtures: 800mm
